MKP4J022203C00KSSD | Wima
MKP-Folienkondensator, 22 nF, ±10 %, 630 V (DC), PP, 10 mm, MKP4J022203C00KSSD
Bestellnr.: 43D5932
EAN: 4099879818997
HTN:
MKP4J022203C00KSSD
MKP 4 0.022µF/630VDC 10% RM10
Herstellerserien: MKP 4
Einzelpreis (€ / Stk.)
0,7378 € *
Sofort verfügbar: 1.007 Stk.
Verfügbar in 4 Tagen: 8.800 Stk.
Lieferzeit ab Hersteller: 23 Wochen **
Gesamtpreis:
0,74 € *
Preisstaffel
Anzahl
Preis pro Einheit*
1 Stk.
0,7378 €
10 Stk.
0,4641 €
50 Stk.
0,3332 €
250 Stk.
0,2773 €
1000 Stk.
0,2380 €
*inkl. MwSt. zzgl. Versandkosten
**Zwischenverkauf vorbehalten
Folienkondensator, MKP4J022203C00KSSD, WIMA
The MKP4J022203C00KSSD is a metallized capacitor with thin layers of aluminium. The layers are vacuum-deposited on the insulating film as conducting electrodes. In the case of a breakdown, the short circuit current causes the thin metal coating to evaporate around the point of failure and an insulating area is formed. This product is used in the high frequency field. This includes resonant circuits, power supplies, deflection circuits, oscillator circuits and audio equipment.
Features
- Hohes Volumen/Kapazitätsverhältnis
- Selbstheilung
- Sehr niedriger Verlustfaktor
- Negative Kapazitätsänderung in Abhängigkeit von der Temperatur
- Sehr geringe dielektrische Absorption
Anwendungen
- Probenahme und Halten
- Zeitmessung
- Oszillierende Kreisläufe
- Hochfrequenzkopplung und -entkopplung
Technische Daten
Anzahl der Pins | 2 | |
Bauform | radial | |
Breite | 4 mm | |
Dielektrikum | PP | |
Höhe | 9 mm | |
Kapazität | 22 nF | |
Länge | 13 mm | |
max. Temperatur | 105 °C | |
min. Temperatur | -55 °C | |
Nennspannung (AC) | 280 V | |
Nennspannung (DC) | 630 V | |
Rastermaß | 10 mm | |
Toleranz | ±10 % |
Download
Logistik
Ursprungsland | DE |
Zolltarifnummer | 85322500 |
Originalverpackung | Bulk mit 3.000 Stück |
Compliance
RoHS konform | Ja |
Stand der RoHS-Richtlinie | 31.03.15 |
SVHC frei | Ja |
