H05RR-F 3G1,00 SCHWARZ | Control Cables
Rubber control line H05RR-F 3 G 1.0 mm², AWG 18, unshielded, black, H05RR-F 3G1,00 SCHWARZ
Unit Price (€ / mtr.)
2.4157 € *
Available: 0 mtr.
Leadtime: On Request **
Total Price:
2.42 € *
Price list
Quantity
Price per unit*
50 mtr.
2.4157 €
100 mtr.
2.0825 €
500 mtr.
1.8088 €
*incl. VAT plus shipping costs
**Subject to prior sale
Rubber-sheathed cables, type H05RR-F.
With rubber outer insulation
Technical specifications
| Core insulation material | rubber | |
| Core colour sequence | VDE 0293-308 | |
| Number of cores | 3 | |
| Version | control line | |
| Outer diameter | 7 mm | |
| AWG cross-section | AWG 18 | |
| Colour | black | |
| Conductor category | CL.5 = fine stranded | |
| Cable material | copper, tin-plated | |
| Cable cross-section | 1.0 mm² | |
| Material | rubber | |
| Rated voltage | 500 V | |
| Rated voltage U0 | 300 V | |
| Test voltage | 2 kV | |
| Shielding | unshielded | |
| Protective conductor available | Yes | |
| Temperature range (active) | -25 °C to 60 °C | |
| Temperature range (unmoved) | -40 °C to 60 °C |
Download
Logistics
| Country of origin | DE |
| Customs tariff number | 85444991 |
| Original Packaging | Ring with 50 meters |
Compliance
| RoHS conform | Yes |
| Date of RoHS guidelines | 3/31/15 |
| SVHC free | Yes |
