H05V-U 1,00/2,4 RT | Insulated stranded wires
PVC-switching wire, H05V-U, 1.0 mm², red, outer Ø 2.6 mm, H05V-U 1,00/2,4 RT
Unit Price (€ / pck.)
33.5461 € *
Available: 0 pck.
Leadtime: 4 Weeks **
Total Price:
33.55 € *
Price list
Quantity
Price per unit*
5 pck.
33.5461 €
10 pck.
32.2728 €
50 pck.
30.8448 €
100 pck.
29.5596 €
*incl. VAT plus shipping costs
**Subject to prior sale
Hook-up cables with PVC outer insulation, type H05V-U.
For protected installation in equipment and lamps
Technical specifications
| Aderisolationsmaterial | PVC | |
| Außendurchmesser | 2.6 mm | |
| Farbe | rot | |
| Halogenfrei | No | |
| Leiterklasse | Kl.1 = eindrähtig | |
| Leitermaterial | Kupfer, blank | |
| Leiterquerschnitt | 1,0 mm² | |
| Nennspannung | 500 V | |
| Nennspannung U0 | 300 V | |
| Norm | VDE 0281 | |
| Prüfspannung | 2 kV | |
| Temperaturbereich (bewegt) | 5 °C bis 70 °C | |
| Temperaturbereich (unbewegt) | -40 °C bis 70 °C |
Download
Logistics
| Ursprungsland | IT |
| Zolltarifnummer | 85444995 |
Compliance
| RoHS konform | Yes |
| Stand der RoHS-Richtlinie | 3/31/15 |
| SVHC frei | Yes |
