H07V-K 1,50/3,1 GN/GE | Insulated stranded wires
PVC-Stranded wire, high flexible, H07V-K, 1.5 mm², green/yellow, outer Ø 3.1 mm, H07V-K 1,50/3,1 GN/GE
Unit Price (€ / mtr.)
0.6069 € *
Available: 203 mtr.
Leadtime: 4 Weeks **
Total Price:
0.61 € *
Price list
Quantity
Price per unit*
1 mtr.
0.6069 €
10 mtr.
0.5236 €
100 mtr.
0.4641 €
500 mtr.
0.4046 €
1000 mtr.
0.3570 €
*incl. VAT plus shipping costs
**Subject to prior sale
Stranded wire, H07V-K 1,50/3,1 GN/GE, N.A.
PVC stranded wire H07V-K according to VDE 0281, cross-section: 1.5 mm², O.D. 3.1 mm, conductor material: copper, bare. Nominal voltage U0/U: 450/750 V.
Technical specifications
| Aderisolationsmaterial | PVC | |
| Außendurchmesser | 3.1 mm | |
| Farbe | grün/gelb | |
| Halogenfrei | No | |
| Leiterklasse | Kl.5 = feindrähtig | |
| Leitermaterial | Kupfer, blank | |
| Leiterquerschnitt | 1,5 mm² | |
| Nennspannung | 750 V | |
| Nennspannung U0 | 450 V | |
| Norm | VDE 0281 | |
| Prüfspannung | 2.5 kV | |
| Temperaturbereich (bewegt) | 5 °C bis 70 °C | |
| Temperaturbereich (unbewegt) | -40 °C bis 70 °C |
Download
Logistics
| Ursprungsland | DE |
| Zolltarifnummer | 85444995 |
| Originalverpackung | Ring mit 100 Meter |
Compliance
| RoHS konform | Yes |
| Stand der RoHS-Richtlinie | 3/31/15 |
| SVHC frei | Yes |
