H07V-K 10/6,2 GN/GE | Insulated stranded wires
PVC-Stranded wire, high flexible, H07V-K, 10 mm², green/yellow, outer Ø 6.2 mm, H07V-K 10/6,2 GN/GE
Unit Price (€ / mtr.)
3.1654 € *
Available: 86 mtr.
Leadtime: 1 Week **
Total Price:
3.17 € *
Price list
Quantity
Price per unit*
1 mtr.
3.1654 €
10 mtr.
2.7370 €
100 mtr.
2.5585 €
500 mtr.
2.4157 €
1000 mtr.
2.2610 €
*incl. VAT plus shipping costs
**Subject to prior sale
Stranded wire, H07V-K 10/6,2 GN/GE, N.A.
PVC stranded wire H07V-K according to VDE 0281, cross-section: 10 mm², O.D. 6.2 mm, conductor material: copper, bare. Nominal voltage U0/U: 450/750 V.
Technical specifications
| Core insulation material | PVC | |
| Outer diameter | 6.2 mm | |
| Colour | green/yellow | |
| Halogen free | No | |
| Conductor category | CL.5 = fine stranded | |
| Cable material | copper, bright | |
| Cable cross-section | 10 mm² | |
| Rated voltage | 750 V | |
| Rated voltage U0 | 450 V | |
| Standard number | VDE 0281 | |
| Test voltage | 2.5 kV | |
| Temperature range (active) | -5 °C to 70 °C | |
| Temperature range (unmoved) | -30 °C to 70 °C |
Download
Logistics
| Country of origin | DE |
| Customs tariff number | 85444995 |
| Original Packaging | Ring with 100 meters |
Compliance
| RoHS conform | Yes |
| Date of RoHS guidelines | 3/31/15 |
| SVHC free | Yes |
