H07V-U 1,50/2,7 WS | Insulated stranded wires
PVC-switching wire, H07V-U, 1.5 mm², white, outer Ø 3.2 mm, H07V-U 1,50/2,7 WS
Unit Price (€ / pck.)
36.9852 € *
Available: 0 pck.
Leadtime: 8 Weeks **
Total Price:
36.99 € *
Price list
Quantity
Price per unit*
5 pck.
36.9852 €
10 pck.
35.5572 €
50 pck.
33.9864 €
100 pck.
32.5822 €
*incl. VAT plus shipping costs
**Subject to prior sale
Hook-up wires, PVC insulation, single-pole, type H07V-U.
Bright copper wire
Cross-section 1.5 mm², outer diameter 2.8 mm,.
Technical specifications
| Core insulation material | PVC | |
| Outer diameter | 3.2 mm | |
| Colour | white | |
| Halogen free | No | |
| Conductor category | CL.1 = stranded | |
| Cable material | copper, bright | |
| Cable cross-section | 1.5 mm² | |
| Rated voltage | 750 V | |
| Rated voltage U0 | 450 V | |
| Test voltage | 2.5 kV | |
| Temperature range (active) | 5 °C to 70 °C | |
| Temperature range (unmoved) | -40 °C to 70 °C |
Download
Logistics
| Country of origin | DE |
| Customs tariff number | 85444995 |
Compliance
| RoHS conform | Yes |
| Date of RoHS guidelines | 3/31/15 |
| SVHC free | Yes |
