05337 A | Power Transformers
Universal transformer, 180 VA, 10 V/12 V/15 V, 6 A, 05337 A
Order No.: 35C150
EAN: 4099891343828
MPN:
05337 A
Unit Price (€ / pc.)
97.9489 € *
Available: 4 pcs.
Leadtime: On Request **
Universal transformers, type UE 6
Electrically isolated windings (types UE 6 with protective winding). Secondary 2 x 0, 10, 12, 15 V. The two secondary windings can be wired in serial or parallel mode to obtain the following secondary voltages: 2, 3, 4, 5, 6, 7, 8, 10, 12, 13, 14, 15, 17, 18, 20, 22, 24, 25, 27, 30 V
Technical specifications
| Output power | 180 W | |
| Width | 94 mm | |
| Height | 110.5 mm | |
| Length | 102 mm | |
| Primary voltage | 230 V | |
| Secondary voltage (1) | 10 V | |
| Secondary voltage (2) | 12 V | |
| Secondary voltage (3) | 15 V | |
| Secondary amperage 1 | 6 A |
Download
Logistics
| Country of origin | DE |
| Customs tariff number | 85043180 |
Compliance
| RoHS conform | Yes |
| Date of RoHS guidelines | 3/31/15 |
| SVHC free | Yes |
