05338 A | Power Transformers
Universal transformer, 15 VA, 20 V/24 V/30 V, 0.25 A, 05338 A
Order No.: 35C160
EAN: 4099891343835
MPN:
05338 A
Unit Price (€ / pc.)
28.0721 € *
Available: 0 pcs.
Leadtime: On Request **
Universal transformers, type UE 7
Electrically isolated windings (types UE 7 with protective winding). Secondary 2 x 0, 20, 24, 30 V. The two secondary windings can be wired in serial or parallel mode to obtain the following secondary voltages: 7: 4, 6, 8, 10, 12, 14, 16, 20, 24, 26, 28, 30, 34, 36, 40, 44, 48, 50, 54, 60 V.
Technical specifications
| Output power | 15 W | |
| Width | 47.7 mm | |
| Height | 60.5 mm | |
| Length | 55 mm | |
| Primary voltage | 230 V | |
| Secondary voltage (1) | 20 V | |
| Secondary voltage (2) | 24 V | |
| Secondary voltage (3) | 30 V | |
| Secondary amperage 1 | 0.25 A |
Download
Logistics
| Country of origin | DE |
| Customs tariff number | 85043180 |
Compliance
| RoHS conform | Yes |
| Date of RoHS guidelines | 3/31/15 |
| SVHC free | Yes |
