2-1437565-8 | Alcoswitch
Short-stroke pushbutton, Form A (N/O), 50 mA/24 V, unlit , actuator (white, L 0.7 mm), 2.54 N, SMD, 2-1437565-8
Unit Price (€ / pc.)
0.1880 € *
Available: 630 pcs.
Leadtime: 23 Weeks **
Total Price:
0.94 € *
Price list
Quantity
Price per unit*
5 pcs.
0.1880 €
10 pcs.
0.1654 €
50 pcs.
0.1404 €
100 pcs.
0.1154 €
*incl. VAT plus shipping costs
**Subject to prior sale
Tactile Switch, 2-1437565-8, Alcoswitch
Illuminated: No, Actuator Style: Round, Dust Proof: No, Snap Action: Without, Operating Function: NO, Support Bracket: Without, Configuration (Pole-Throw): Single Pole - Single Throw, Number of Actuators: 1, Tactile Switch Voltage Rating: 24 VDC, Actuator Material: Nylon, Actuator Color: White, Contact Base Material: Copper Alloy, Switch Contact Plating Material: Silver, Tactile Switch Contact Current Rating: 50 mA, Termination Type: Printed Circuit Board, Tactile Switch Mounting Type: Surface Mount, Tactile Switch Mounting Angle: Vertical, Low Profile: With, Process Sealed: No, Actuator Length: .7 mm, Temperature Rating: Standard °C, Packaging Method: Loose Piece, Comment: (On) indicates momentary position.
Technical specifications
| Anschluss | SMD | |
| beleuchtet | No | |
| Betätigungskraft | 2,54 N | |
| Breite | 6 mm | |
| Farbe Betätiger | weiß | |
| Höhe | 4.3 mm | |
| Kontaktmaterial | versilbert | |
| Länge | 6 mm | |
| Schaltfunktion | Schließer | |
| Schaltleistung | 50 mA/24 V | |
| Betätigerlänge | 0.7 mm |
Download
Logistics
| Ursprungsland | CN |
| Zolltarifnummer | 85365080 |
Compliance
| RoHS konform | Yes |
| Stand der RoHS-Richtlinie | 3/31/15 |
| SVHC frei | Yes |
