1-1825137-5 | Alcoswitch
Toggle switch, metal, 1 pole, latching, On-Off-On, 0.4 VA/20 V AC/DC, gold-plated, 1-1825137-5
Unit Price (€ / pc.)
4.7600 € *
Available: 20 pcs.
Leadtime: 18 Weeks **
Total Price:
4.76 € *
Price list
Quantity
Price per unit*
1 pcs.
4.7600 €
10 pcs.
4.3792 €
50 pcs.
3.9865 €
100 pcs.
3.5819 €
*incl. VAT plus shipping costs
**Subject to prior sale
Toggle Switch, 1-1825137-5, Alcoswitch
Product Type: Switch, Sealed Toggle Switch: Yes, Toggle Style: Baton Long, Toggle Switch Type: Toggle, Toggle Actuation: Vertical, Configuration (Pole-Throw): Single Pole - Double Throw, Operating Function: On Off On, Contact Resistance: 10 mΩ, Toggle Switch Voltage Rating: 20 VDC, Toggle Switch Voltage Rating: 20 V, Toggle Switch Voltage Rating: 20 VAC, Actuator Finish: Nickel, Bushing Thread Size: 1/4-40, Toggle Switch Seal Type: Terminal Seal (Epoxy), Bushing Style: Threaded, Contact Base Material: Copper, Switch Contact Plating Material: Gold, Toggle Switch Contact Current Rating: .4 A, Termination Type: Printed Circuit, Toggle Switch Mounting Type: Through Hole, Process Sealed: No, Bushing Length: , UL Flammability Rating: UL 94V-1
Technical specifications
| Anschluss | Leiterplattenanschluss | |
| Bauform | stehend | |
| Befestigungsart | Zentralbefestigung | |
| beleuchtet | No | |
| Farbe Betätiger | metall | |
| Kontaktoberfläche | vergoldet | |
| Polzahl | 1-polig | |
| Schaltfunktion | rastend | |
| Schaltleistung | 0,4 VA/20 V AC/DC | |
| Schaltstellung | Ein-Aus-Ein |
Download
Logistics
| Ursprungsland | IN |
| Zolltarifnummer | 85365080 |
Compliance
| RoHS konform | Yes |
| Stand der RoHS-Richtlinie | 3/31/15 |
| SVHC frei | No |
| Substanz Beschreibung | Blei |
