Socket housing, 1534404-1, AMP
Row-to-row spacing: 4.24 mm, Connector & housing type: housing for female terminals, Connector system: wire-to-board, wire-to-device, wire-to-wire, Sealable: no, Hybrid connector: no, Number of positions: 4, Number of rows: 2, Nominal voltage architecture: 24 V, Operating voltage: 24 VDC, Cable exit angle: 180°, Body material: PBT GF, Primary product color: black, Mating tab width: 6.3 mm, Terminal position assurance: yes, Centerline (pitch): 6 mm, Height: 22.8 mm, Length: 25 mm, Width: 24.36 mm, Operating temperature (max): 70 °C, 75 °C, 80 °C, 85 °C, Operating temperature range: -40-85 °C, -40-85 °C, Circuit application: power, UL flammability rating: UL 94-HB, Packaging method: carton, Packaging quantity: 1200, Serviceable: yes, Connector position assurance capable: no
