353900-4 | AMP
Plug, unequipped, 7 pole, straight, 3 rows, green, 353900-4
Unit Price (€ / pc.)
3.3915 € *
Available: 0 pcs.
Available in 5 Days: 187 pcs.
Leadtime: 24 Weeks **
Plug housing, 353900-4, AMP
Connector & housing type: housing for male terminals, Connector system: wire-to-wire, Sealable: no, Hybrid connector: no, Primary locking feature: integrated in housing, Number of positions: 7, Number of rows: 3, Operating voltage: 12 VDC, Nominal voltage architecture: 12 V, Body material: PBT GF, Primary product color: green, Mating tab width: 0.8 mm, Mating alignment type: polarized, Centerline (pitch): 2 mm, Row-to-row spacing: 2.4 mm, Operating temperature (max): 70 °C, 75 °C, 80 °C, 85 °C, 90 °C, 100 °C, 105 °C, Operating temperature range: -40-105 °C, Circuit application: signal, Packaging method: bag, Serviceable: yes, Connector position assurance capable: no
Technical specifications
| Connection | crimp connection | |
| Number of rows | 3 | |
| Version | straight | |
| Additional parts | unequipped | |
| Colour | green | |
| Contact type | plug | |
| Rated voltage | 12 V | |
| Pin number | 7 pole | |
| Grid | 2 mm | |
| Type of locking | Yes |
Download
Logistics
| Country of origin | TH |
| Customs tariff number | 85389091 |
Compliance
| RoHS conform | Yes |
| Date of RoHS guidelines | 3/31/15 |
| SVHC free | Yes |
