964596-1 | AMP
Socket, unequipped, 6 pole, straight, 2 rows, yellow, 964596-1
Order No.: 36P4351
EAN: 4099889906431
MPN:
964596-1
Unit Price (€ / pc.)
3.8913 € *
Available: 0 pcs.
Leadtime: 11 Weeks **
Total Price:
19,456.50 € *
*incl. VAT plus shipping costs
**Subject to prior sale
5000 pcs.
3.8913 €
Socket housing, 964596-1, AMP
Connector & housing type: housing for female terminals, Connector system: wire-to-wire, Sealable: no, Hybrid connector: no, Primary locking feature: integrated in housing, Number of positions: 6, Number of rows: 2, Body material: PA GF, Primary product color: yellow, Strain relief: no, Centerline (pitch): 11 mm, Row-to-row spacing: 11 mm, Operating temperature (max): 70 °C, 75 °C, 80 °C, 85 °C, 90 °C, 100 °C, 105 °C, 110 °C, 120 °C, 125 °C, 130 °C, Operating temperature range: -40-130 °C, UL flammability rating: UL 94HB, Packaging method: box, Serviceable: no, Connector position assurance capable: no
Technical specifications
| Connection | Crimpanschluss | |
| Number of rows | 2 | |
| Version | gerade | |
| Additional parts | unbestückt | |
| Colour | gelb | |
| Contact type | Buchse | |
| Rated voltage | 12 V | |
| Pin number | 6-polig | |
| Grid | 11 mm | |
| Type of locking | Ja |
Download
Logistics
| Country of origin | CN |
| Customs tariff number | 39269097 |
Compliance
| RoHS conform | Yes |
| Date of RoHS guidelines | 3/31/15 |
| SVHC free | Yes |
