1-1377173-3 | AMP

Name: Insulated ring cable lug, 3-6 mm², AWG 12 to 10, 10.5 mm, M10, yellow, 1-1377173-3
Brand: AMP
SKU: 71P0355
Price: 1.17 EUR
Availability: OutOfStock

Insulated ring cable lug, 3-6 mm², AWG 12 to 10, 10.5 mm, M10, yellow, 1-1377173-3

Order No.: 71P0355

EAN: 4099891602741

MPN:

1-1377173-3

Series: PLASTI-GRIP

Image may differ

Key Specification:

Version ring cable lug

Cable cross-section 3-6 mm²

AWG cross-section AWG 12 to 10

Isolated Yes

Colour yellow

Ordering Information:

not to be sold to private customers

Download Datasheet Technical specifications

Unit Price (€ / pc.)

1.1662 € *

Available: 0 pcs.

Available in 5 Days: 2,222 pcs.

Leadtime: 46 Weeks **

Add to Cart

Total Price:

1.17 € *

Price list

Quantity

Price per unit*

100 pcs.

1.1662 €

450 pcs.

0.9758 €

*incl. VAT plus shipping costs

**Subject to prior sale

Description

Ring cable lug, 1-1377173-3, AMP

Ring terminal, Ring tongue, 12-10 AWG Wire size, 3-6 mm² Wire size, 5180-13100 CMA Wire size, Stud size M10.

Technical specifications

	Version	ring cable lug
	AWG cross-section	AWG 12 to 10
	Colour	yellow
	Thread size	M10
	Isolated	Yes
	Cable cross-section	3-6 mm²
	Hole diameter	10.5 mm
	Material	copper, tin-plated
	max. operating temperature	105 °C
	shrinkable tubing	Yes
