327289 | AMP
Uninsulated ring cable lug, 253 mm², 14.27 mm, metal, 327289
Unit Price (€ / pc.)
45.5175 € *
Available: 0 pcs.
Available in 5 Days: 22 pcs.
Leadtime: 37 Weeks **
Rings and Spades, 327289, AMP
Ring & Spade Stud Size: 1/2,M12, Ring & Spade Barrel Type: Closed Barrel, Sealable: No, Insulated: No, Ring & Spade Wire/Cable Type: Copper, Number of Holes: 2, Terminal Angle: Straight, Weight per Piece: 209.106 g, Ring & Spade Plating Material: Tin, Military Part Class: Class II, Terminal & Splice Type: Rectangular Tongue, Ring & Spade Terminal Orientation: Straight, Wire Insulation Support: Without, Wire Size: 253 mm², Wire Size: 450000 – 550000 CMA, Stud Diameter: 14.27 mm, Tongue Thickness: 5.08 mm, Ring & Spade Overall Length: 121.9 mm, Operating Temperature Range: -55 – 105 °C, Heavy Duty: No, Government Qualified: No, Packaging Quantity: 25, Ring & Spade Packaging Method: Box, Comment: Electrodeposited Tin Plate per MIL-T-10727.
Technical specifications
| Version | Ringkabelschuh | |
| Colour | metall | |
| Isolated | No | |
| Cable cross-section | 253 mm² | |
| Hole diameter | 14.27 mm | |
| Material | Zinn | |
| max. operating temperature | 105 °C |
Download
Logistics
| Country of origin | TH |
| Customs tariff number | 85366990 |
Compliance
| RoHS conform | Yes |
| Date of RoHS guidelines | 3/31/15 |
| SVHC free | Yes |
