166053-1 | AMP

Pin contact, 0.2-0.56 mm², AWG 24-20, crimp connection, gold-plated, 166053-1

Order No.: 36P8589
EAN: 4099889647655
MPN:
166053-1
Series: AMPLIMITE
166053-1 AMP Crimp Contacts
Image may differ
Unit Price (€ / pc.)
0.4879 € *
Available: 10,800 pcs.
Available in 5 Days: 37,500 pcs.
Leadtime: 4 Weeks **
Total Price:
4.88 € *
Price list
Quantity
Price per unit*
10 pcs.
0.4879 €
100 pcs.
0.3927 €
500 pcs.
0.3451 €
1000 pcs.
0.2808 €
*incl. VAT plus shipping costs
**Subject to prior sale

Pin contact, 166053-1, AMP

Grade: Standard, Connector System: Cable-to-Cable, Connector & Contact Terminates To: Wire & Cable, Color Code: Red, PCB Contact Termination Area Plating Material: Tin, Contact Type: Pin, D-Sub Contact Size: 20, Contact Base Material: Brass, Contact Mating Area Plating Material: Gold, Termination Method to Wire & Cable: Crimp, Wire Insulation Support: With, Accepts Wire Insulation Diameter Range: 1.27 - 1.52 mm, Wire Size: 24 - 20 AWG, Wire Size: 0.2 - 0.56 mm², Operating Temperature Range: -55 - 105 °C.

Technical specifications
Ausführung Stiftkontakt
Leiterquerschnitt 0,2-0,56 mm²
AWG-Leiterquerschnitt AWG 24-20
Kontaktanschluss Crimpanschluss
Kontaktmaterial Messing
Kontaktoberfläche Steckbereich vergoldet
Kontaktoberfläche vergoldet
Kontaktoberfläche Anschlussbereich vernickelt
Isolationsdurchmesser 1,52 mm
Logistics
Ursprungsland CN
Zolltarifnummer 85366990
Originalverpackung Rolle mit 12.500 Stück
Compliance
RoHS konform Yes
Stand der RoHS-Richtlinie 3/31/15
SVHC frei Yes
