925553-2 | AMP
Pin contact, 1.0-2.5 mm², AWG 17-13.5, crimp connection, tin-plated, 925553-2
Order No.: 34P9770
EAN: 4099889636581
MPN:
925553-2
Unit Price (€ / pc.)
0.1059 € *
Available: 0 pcs.
Available in 5 Days: 14,000 pcs.
Leadtime: 20 Weeks **
Total Price:
4,448.22 € *
*incl. VAT plus shipping costs
**Subject to prior sale
42000 pcs.
0.1059 €
Crimp wire pins, tabs and ferrules, 925553-2, AMP
Crimp Wire Pin, Tab & Ferrule Barrel Type: Open Barrel, Insulated: No, Support Style: Insulation Support, Crimp Wire Pin, Tab & Ferrule Plating Material: Pre-Tin, Terminal & Splice Type: Pin, Crimp Wire Pin, Tab & Ferrule Terminal Type: Pin, Crimp Wire Pin, Tab & Ferrule Pin Diameter: 3.2 mm, Crimp Wire Pin, Tab & Ferrule Terminal Orientation: Straight, Wire Insulation Support: With, Crimp Wire Pin, Tab & Ferrule Wire Insulation Diameter (Max): 3.8 mm, Accepts Wire Insulation Diameter Range: 2.5 - 3.8 mm, Wire Size: 17 - 13 AWG, Wire Size: 1 - 2.5 mm², Wire Size: 2048 - 5178 CMA Heavy Duty: No, Packaging Quantity: 14000, Crimp Wire Pin, Tab & Ferrule Packaging Method: Roll, Comment: According to DIN 46228, Part 2.
Technical specifications
| Version | Stiftkontakt | |
| AWG cross-section | AWG 17-13,5 | |
| Insulation diameter | 2,5-3,8 mm | |
| Contact connection | Crimpanschluss | |
| Contact material | Messing | |
| contact surface | verzinnt | |
| Cable cross-section | 1,0-2,5 mm² |
Download
Logistics
| Country of origin | DE |
| Customs tariff number | 85366990 |
Compliance
| RoHS conform | Yes |
| Date of RoHS guidelines | 3/31/15 |
| SVHC free | Yes |
