5-747909-2 | AMP
D-Sub socket, 15 pole, standard, equipped, straight, solder cup, 5-747909-2
Unit Price (€ / pc.)
5.3431 € *
Available: 26 pcs.
Leadtime: 3 Weeks **
Socket headers with solder contacts, type TE Connectivity/AMP HD-20 5-7479...-2.
with metal hood, ground connection and Galvanized outer housing. Contact material: phosphor bronze.Contact finish: 0.76 µm gold plating on nickel primer. Housing material: glass fiber-reinforced polyester, UL 94 V-0. Color: black. Material metal bracket: tinned steel. Rated current: max. 6.0 A. Insulation resistance:min. 500 Mohm. Dielectric strength: min. 1000 VAC. Operating temperatures: - 55 to +105 °C. Mounts:UNC 4-40 nut, UNC 4-40 screw lock, or 3.1 mm through hole.
Technical attributes (type, number of poles, dimensions, mounting, with/without integrated mounting clips): 5-747909-2, 15-pole, A 39.2, B 33.32
Technical specifications
| Version | socket header | |
| Attachment (rear panel) | through hole | |
| Additional parts | equipped | |
| Contact connection | solder cup | |
| Assembly | straight | |
| Pole image | standard | |
| Pin number | 15 pole | |
| Grid | 2.77 mm | |
| Type of locking | through hole |
Download
Logistics
| Country of origin | GB |
| Customs tariff number | 85366990 |
Compliance
| RoHS conform | Yes |
| Date of RoHS guidelines | 3/31/15 |
| SVHC free | Yes |
