1-282042-5 | AMP
Socket housing, 2 pole, pitch 5 mm, angled, black, 1-282042-5
Order No.: 35P3984
EAN: 4099889932034
MPN:
1-282042-5
Unit Price (€ / pc.)
0.3808 € *
Available: 0 pcs.
Leadtime: 4 Weeks **
Total Price:
0.38 € *
Price list
Quantity
Price per unit*
1 pcs.
0.3808 €
10 pcs.
0.3451 €
50 pcs.
0.3094 €
100 pcs.
0.2820 €
*incl. VAT plus shipping costs
**Subject to prior sale
PCB Connection System, 1-282042-5, AMP
Wire-to-Board, Wire & Cable, 2 Position
Technical Data
- Connector Mounting Type: Cable Mount (Free-Hanging)
- Contact Type: Female
- Contact Base Material: Brass
- Housing Material: PA 6.6 GF
- Housing Color: black
- Number of positions: 2
- Operating Temperature Range: -25 – 105 °C [-13 – 221 °F]
- Rated current: 6 A
- Centerline (Pitch): 5 mm
- PCB Mount Retention: Without
- Sealable: No
- Contact Layout: Inline
Technical specifications
| Connection | IDC connection | |
| Connection plating | tin-plated | |
| Number of rows | 1 | |
| Version | socket housing | |
| Additional parts | equipped | |
| Colour | black | |
| Contact type | socket | |
| contact surface | tin-plated | |
| Rated voltage | 150 V | |
| Rated current | 6 A | |
| Orientation | angled | |
| Pin number | 2 pole | |
| Grid | 5 mm |
Download
Logistics
| Country of origin | IN |
| Customs tariff number | 85366910 |
Compliance
| RoHS conform | Yes |
| Date of RoHS guidelines | 3/31/15 |
| SVHC free | Yes |
