5-102398-2 | AMP
Socket header, 8 pole, pitch 2.54 mm, straight, black, 5-102398-2
Unit Price (€ / pc.)
2.7013 € *
Available: 0 pcs.
Leadtime: 37 Weeks **
Wire-to-Board Connector Assemblies and Housings, 5-102398-2, AMP
Applied Pressure: Standard, Connector Product Type: Connector Assembly, Connector & Housing Type: Receptacle, Connector System: Wire-to-Board, Sealable: No, Number of Positions: 8, Number of Rows: 2, Insulation Resistance: 5000 MΩ, Contact Base Material: Copper Alloy, Contact Current Rating (Max): 3 A, Termination Method to Wire & Cable: Insulation Displacement Crimp (IDC), Mating Retention: Without, Connector Mounting Type: Cable Mount (Free-Hanging), Housing Material: Thermoplastic, Centerline (Pitch): 2.54 mm, Housing Color: Black, Wire Size: .12 – .326 mm², Row-to-Row Spacing: 2.54 mm, Operating Temperature Range: -65 – 105 °C, Circuit Application: Signal, UL Flammability Rating: UL 94V-0, Packaging Method: Tray
Technical specifications
| Connection | Schneidklemmanschluss | |
| Connection plating | verzinnt | |
| Number of rows | 2 | |
| Version | Buchsenleiste | |
| Additional parts | bestückt | |
| Colour | schwarz | |
| Contact type | Buchse | |
| contact surface | verzinnt | |
| Rated current | 3 A | |
| Orientation | gerade | |
| Pin number | 8-polig | |
| Grid | 2.54 mm |
Download
Logistics
| Country of origin | IT |
| Customs tariff number | 85366930 |
Compliance
| RoHS conform | Yes |
| Date of RoHS guidelines | 3/31/15 |
| SVHC free | Yes |
