5-215915-0 | AMP
Socket header, 50 pole, pitch 2.54 mm, angled, gray, 5-215915-0
Unit Price (€ / pc.)
1.9159 € *
Available: 0 pcs.
Available in 5 Days: 500 pcs.
Leadtime: 4 Weeks **
Total Price:
1.92 € *
Price list
Quantity
Price per unit*
50 pcs.
1.9159 €
250 pcs.
1.8802 €
*incl. VAT plus shipping costs
**Subject to prior sale
PCB Connection System, 5-215915-0, AMP
Wire-to-Board, Wire & Cable, 50 Position
Technical Data
- Connector Mounting Type: Cable Mount (Free-Hanging)
- Housing Color: gray
- Number of positions: 50
- Operating Temperature Range: -65 – 105 °C [-85 – 221 °F]
- Rated current: 1 A
- Centerline (Pitch): 2.54 mm
- Row-to-Row Spacing: 2.54 mm [0.1 in]
Technical specifications
| Connection | IDC connection | |
| Connection plating | tin-plated | |
| Number of rows | 2 | |
| Version | socket header | |
| Additional parts | equipped | |
| Colour | gray | |
| Contact type | socket | |
| contact surface | gold-plated | |
| Rated current | 1 A | |
| Orientation | angled | |
| Pin number | 50 pole | |
| Grid | 2.54 mm |
Download
Logistics
| Country of origin | TW |
| Customs tariff number | 85369001 |
Compliance
| RoHS conform | Yes |
| Date of RoHS guidelines | 3/31/15 |
| SVHC free | Yes |
