60384-2 | AMP
Uninsulated flat plug sleeve, 6.35 x 0.81 mm, 0.51 to 1.31 mm², AWG 20 to 16, brass, tin-plated, 60384-2
Unit Price (€ / pc.)
0.1083 € *
Available: 0 pcs.
Available in 5 Days: 132,000 pcs.
Leadtime: 26 Weeks **
Total Price:
1,299.48 € *
Price list
Quantity
Price per unit*
12000 pcs.
0.1083 €
24000 pcs.
0.1047 €
*incl. VAT plus shipping costs
**Subject to prior sale
Flat receptacle, 60384-2, TE Connectivity
Terminates To: Wire & Cable, Insertion Force: Low, Sealable: No, Insulated: No, Connection Capacity: Single, Fully Insulated: No, Plating Material: Tin, Terminal Type: Receptacle, Terminal & Splice Type: Receptacle, Terminal Orientation: Straight, Contact Base Material: Brass, Crimp Type: F-Crimp, Wire Insulation Support: Without, Receptacle Terminal Stock Thickness: 0.4 mm, Wire Size: 20 – 16 AWG, Wire Size: 0.51 – 1.31 mm², Wire Size: 1000 – 3000 CMA, Mating Tab Width: 6.35 mm, CSA Certified: Yes, Packaging Quantity: 12000, Packaging Method: Reel
Technical specifications
| Connection | crimp connection | |
| Version | flat plug sleeve | |
| AWG cross-section | AWG 20 to 16 | |
| Suitable for | 6.35 x 0.81 mm | |
| Isolated | No | |
| Length | 17.53 mm | |
| Cable cross-section | 0.51 to 1.31 mm² | |
| Material | brass, tin-plated |
Download
Logistics
| Country of origin | GB |
| Customs tariff number | 85366990 |
Compliance
| RoHS conform | Yes |
| Date of RoHS guidelines | 3/31/15 |
| SVHC free | Yes |
