Q12F1CXXW24E | APEM
LED signal light, 24 V (DC), white, 1.56 cd, Mounting Ø 12 mm, pitch 2.54 mm, LED number: 1, Q12F1CXXW24E
LED-Signal lamp, Q12F1CXXW24E, APEM
The Q12F1CXXW24E LED Indicator is a versatile and reliable product that is perfect for a wide range of applications. With a 12 mm Mounting Hole, it can be easily installed in various devices and equipment. The Flush Bezel Style gives it a sleek and modern look, making it a great choice for any design aesthetic. It features Solder Lug Fastons 28 x 08 Terminals, ensuring a secure and stable connection. The Bright Chrome Bezel Finish adds a touch of elegance to the indicator. With Fixed Light Type Of Illumination, it provides a steady and consistent light source. The White LED Color is bright and clear, making it easy to see in any environment. Operating at 24 VDC Voltage, it is energy-efficient and cost-effective. Additionally, it has a high level of sealing with an IP67 rating, ensuring its durability and resistance to dust and water. Choose the Q12F1CXXW24E LED Indicator for your next project and experience its exceptional quality and performance.
| Connection | solder connection/2.8 mm | |
| Number of LEDs | 1 | |
| Diode Diameter | 8 mm | |
| Installation diameter | 12 mm | |
| Farbe der Beleuchtung | white | |
| Luminous intensity | 1.56 cd | |
| Assembly | PCB mounting | |
| Rated voltage (DC) | 24 V | |
| Rated current | 20 mA | |
| Grid | 2.54 mm |
| Country of origin | GB |
| Customs tariff number | 85414100 |
| RoHS conform | Yes |
| Date of RoHS guidelines | 3/31/15 |
| SVHC free | Yes |
