RB150 5% 22R | ATE ELECTRONICS

Wirewound resistor, 22 Ω, 150 W, ±5 %, RB150 5% 22R

Order No.: 63E5726
EAN: 4099879703088
MPN:
RB150 5% 22R
Series: RB150
ATE ELECTRONICS
RB150 5% 22R ATE ELECTRONICS Wirewound Resistors
Image may differ
Print
Key Specification:
ohmic resistance 22 Ω
Tolerance ±5 %
Power 150 W
Design chassis
Assembly chassis mounting
Show 28 variants
Download Datasheet Technical specifications
Unit Price (€ / pc.)
20.8845 € *
Available: 3 pcs.
Leadtime: 7 Weeks **
Total Price:
20.88 € *
Price list
Quantity
Price per unit*
1 pcs.
20.8845 €
10 pcs.
18.3736 €
50 pcs.
17.1241 €
150 pcs.
16.3863 €
500 pcs.
15.5414 €
*incl. VAT plus shipping costs
**Subject to prior sale
Description
Technical specifications
Download
Logistics
Compliance
Variations

150 W, tolerance 5.0 %, type ATE RB 150.
Technical specifications
ohmic resistance 22 Ω
Version high load wire resistor
Design chassis
Width 47.5 mm
Height 24 mm
Length 97 mm
Power 150 W
max. operating temperature 250 °C
min. operating temperature -55 °C
Assembly chassis mounting
nominal load capacity without cooling surface 55 W
Tolerance ±5 %
Temperature coefficient 30 ppm/K
Show similar products 0
Logistics
Country of origin IT
Customs tariff number 85332100
Compliance
RoHS conform Yes
Date of RoHS guidelines 3/31/15
SVHC free Yes
