Name: Wirewound resistor, 39 Ω, 25 W, ±5 %, RB25 5% 39R
Brand: ATE ELECTRONICS
SKU: 63E4754
Price: 4.19 EUR
Availability: InStock

Wirewound resistor, 39 Ω, 25 W, ±5 %, RB25 5% 39R

Order No.: 63E4754

EAN: 4099879701657

MPN:

RB25 5% 39R

Series: RB

Image may differ

Key Specification:

ohmic resistance 39 Ω

Tolerance ±5 %

Power 25 W

Design chassis

Assembly chassis mounting

Show 26 variants

Download Datasheet Technical specifications

Unit Price (€ / pc.)

4.1888 € *

Available: 147 pcs.

Leadtime: 7 Weeks **

Total Price:

4.19 € *

Price list

Quantity

Price per unit*

1 pcs.

4.1888 €

10 pcs.

3.8794 €

100 pcs.

3.6652 €

500 pcs.

3.4510 €

1000 pcs.

3.2844 €

*incl. VAT plus shipping costs

**Subject to prior sale

Description

Wire-wound power resistors, 25 W, tolerance 5.0 %, type ATE RB 25.

High thermal conductivity, excellent heat dissipation due to aluminum profile heatsink, certified to MiL-PRF-18546 G

Download

Technical Data Sheet - EN Technical Data Sheet

Declaration of Conformity - EN Declaration of Conformity

Declaration of Conformity - DE Declaration of Conformity

Logistics

Country of origin	IT
Customs tariff number	85332100

Compliance

RoHS conform	Yes
Date of RoHS guidelines	3/31/15
SVHC free	Yes

1 item in 26 variations
