8-1393792-7 | AXICOM
Relay, 2 Form C (NO/NC), 6 V (DC), 240 Ω, 3 A, 220 V (DC), 250 V (AC), monostable, 8-1393792-7
Unit Price (€ / pc.)
3.2606 € *
Available: 0 pcs.
Available in 5 Days: 2,425 pcs.
Leadtime: 16 Weeks **
Total Price:
3.26 € *
Price list
Quantity
Price per unit*
50 pcs.
3.2606 €
150 pcs.
3.2011 €
*incl. VAT plus shipping costs
**Subject to prior sale
Signal relay, 8-1393792-7, AXICOM
Signal relay, 220 VDC Contact Voltage, 250 VAC Contact Voltage, 150 mW Coil Power (DC), Printed circuit board, PCB-THT.
Features
- Immersion cleanable
- Standard DIL relay
Applications
- Communications equipment
- Office equipment
- Measurement and control equipment
- Entertainment electronics
- Medical equipment
- Consumer electronics
Technical specifications
| Connection | PCB pin | |
| Contact type | 2 Form C (NO/NC) | |
| Contact material | AgNi | |
| Switching Voltage (AC) | 250 V | |
| Switching Voltage (DC) | 220 V | |
| switching current | 3 A | |
| Coil voltage (DC) | 6 V | |
| Coil type | monostable | |
| Coil resistance | 240 Ω |
Download
Logistics
| Country of origin | CZ |
| Customs tariff number | 85364900 |
Compliance
| RoHS conform | Yes |
| Date of RoHS guidelines | 3/31/15 |
| SVHC free | Yes |
