64WR10KLF | BI Technologies
Cermet trimmer potentiometer, 12 turns, 10 kΩ, 0.25 W, THT, on top, 64WR10KLF
Unit Price (€ / pc.)
2.9036 € *
Available: 2,199 pcs.
Leadtime: 15 Weeks **
Total Price:
2.90 € *
Price list
Quantity
Price per unit*
1 pcs.
2.9036 €
50 pcs.
2.4752 €
100 pcs.
2.3681 €
200 pcs.
2.2848 €
1000 pcs.
2.0587 €
*incl. VAT plus shipping costs
**Subject to prior sale
Trimmer potentiometer, 64WR10KLF, BI Technologies
The multi-turn trimmer fromBI Technologiesogies brand is sealed to withstand aggressive water wash and have a very long life. This trimmer offers unmatched quality and reliability with efficient space saving.
Applications
- Consumer electronics
- Medical applications
- Any application requiring adjustability or calibration
- Air conditioners
- Computer monitors
Technical specifications
| ohmscher Widerstand | 10 kΩ | |
| Anschluss | Lötstift | |
| Ausführung | Cermet-Trimmpotentiometer | |
| Breite | 4 mm | |
| Drehbereich (elektrisch) | 4320 ° | |
| Einstellung | oben | |
| Höhe | 6.86 mm | |
| Kontaktabstand | RM 2,54 | |
| Länge | 6 mm | |
| Leistung | 0.25 W | |
| max. Anzahl der Umdrehungen | 12 | |
| max. Temperatur | 150 °C | |
| min. Temperatur | -65 °C | |
| Montage | THT | |
| Toleranz | ±10 % | |
| Temperaturkoeffizient | ±100 ppm/K | |
| Widerstandsverlauf | linear |
Download
Logistics
| Ursprungsland | MX |
| Zolltarifnummer | 85334010 |
| Originalverpackung | Stange mit 50 Stück |
Compliance
| RoHS konform | Yes |
| Stand der RoHS-Richtlinie | 3/31/15 |
| SVHC frei | Yes |
