09 0454 80 14 | binder

Panel socket, 14 pole, solder cup, screw locking, straight, 09 0454 80 14

Order No.: 66F758
EAN: 4099889728781
MPN:
09 0454 80 14
Series: 723
binder
09 0454 80 14 binder Other Circular Connectors Image 1
09 0454 80 14 binder Other Circular Connectors Image 2
09 0454 80 14 binder Other Circular Connectors Image 3
Image may differ
Unit Price (€ / pc.)
27.7151 € *
Available: 0 pcs.
Available in 5 Days: 100 pcs.
Leadtime: On Request **
Total Price:
27.72 € *
Price list
Quantity
Price per unit*
1 pcs.
27.7151 €
10 pcs.
24.3831 €
50 pcs.
22.7290 €
150 pcs.
21.7294 €
500 pcs.
20.6227 €
*incl. VAT plus shipping costs
**Subject to prior sale

Circular connector, type Binder 423../723.

Robust, water-proof, with screwed cable gland. Compatible with other products which have the same contact arrangement; Contacts: female, copper tin. Male contacts: copper zinc. Contact finish: 2- to 8-pole silver-plated, 12- and 24-pole: gold-plated. Cable connection: solder contacts, 2- to 8-pole max. 0.75 mm², 12- and 19-pole max. 0.25 mm², 24-pole max. 0.14 mm². Contact carrier: PBT to UL 94 V-0. Straight cable housing: nickel-plated brass. Angled cable housing: zinc die-cast, nickel-plated. Flanged housing: zinc die-cast, nickel-plated. Cable entry: 4.0 to 6.0 mm (Pg 7), 6.0 to 8.0 mm (Pg 9). Degree of protection in mated state (IEC 60529): IP 67. Test voltage: 2- to 5-pole (without 5-pole stereo) 1750 VAC, 5-pole stereo and 8- to 24-pole 550 VAC, 6- and 7-pole 910 V. Contact resistance: 2- to 8-pole max. 5.0 mohm, 12- and 24-pole max. 3.0 mohm. Insulation resistance: at least 10 Gohm. Insertion cycles: at least 500. Operating temperatures: –30 to +95 °C.

Front screw mount, solder terminals, type 723.

Technical attributes (type, number of poles, rated voltage/rated current (40 °C)): 09-0454-80-14, 14-pole, 60 V/3.0 A

Technical specifications
Version panel socket
Additional parts equipped
Shell Material zinc die casting
Contact connection solder cup
contact surface gold-plated
Cable cross-section 0.25 mm²
Assembly PCB mounting
Orientation straight
Pin number 14 pole
Type of locking screw locking
Logistics
Country of origin DE
Customs tariff number 85369010
Compliance
RoHS conform Yes
Date of RoHS guidelines 3/31/15
SVHC free No
Substance description Lead
