77 3403 0000 20012-0500 | binder
Sensor actuator cable, M8-cable plug, angled to open end, 12 pole, 5 m, PVC, gray, 1 A, 77 3403 0000 20012-0500
Unit Price (€ / pc.)
33.2248 € *
Available: 0 pcs.
Leadtime: On Request **
Total Price:
33.22 € *
Price list
Quantity
Price per unit*
1 pcs.
33.2248 €
10 pcs.
31.2256 €
25 pcs.
29.0360 €
50 pcs.
27.0011 €
*incl. VAT plus shipping costs
**Subject to prior sale
Sensor actuator cable, 77 3403 0000 20012-0500, binder
M8 Male angled connector, Contacts: 12, unshielded, moulded on the cable, IP67, PVC, grey, 12 x AWG 28, 5 m.
Technical specifications
| Connection (1) | M8-cable plug, angled | |
| Connection (2) | open end | |
| Colour | gray | |
| Cable length | 5 m | |
| LED display | No | |
| Material | PVC | |
| max. Voltage | 30 V | |
| Rated current | 1 A | |
| Pin number | 12 pole | |
| Degree of protection (IP) | IP67 |
Download
Logistics
| Country of origin | DE |
| Customs tariff number | 85444290 |
Compliance
| RoHS conform | Yes |
| Date of RoHS guidelines | 3/31/15 |
| SVHC free | No |
