BK1696B | BK PRECISION
20 V / 10 A Programmable DC Power Supply
Order No.: 35K0015
EAN: 817050169614
MPN:
BK1696B
Unit Price (€ / pc.)
554.54 € *
Available: 0 pcs.
Leadtime: 3 Weeks **
DC Power supply, BK1696B, BK PRECISION
The BK1696B DC power supply is equipped with programming and protection features commonly found in more expensive performance instruments. Programming features include list mode for repetitive operation and 10 user-configurable voltage/current presets for quick recall. This benchtop power supply also supports adjustable voltage and current limits to protect the device under test.
Suitable for many applications including repetitive test routines in RandD, production testing, product evaluation, or in education environments.
Features
- Built-in voltage, current, and power meter
- Automatic CV/CC crossover operation
- Protection features: overvoltage (OVP), overcurrent (OCP), overtemperature (OTP) and key-lock function
- Store up to 10 voltage and current combinations for quick output
- Lightweight and compact
- Large back-lit LCD display
- Thermostatically-controlled fan with linear-speed control to minimize fan noise
Download
Logistics
| Ursprungsland | CN |
| Zolltarifnummer | 85044095 |
Compliance
| RoHS konform | Yes |
| Stand der RoHS-Richtlinie | 3/31/15 |
| SVHC frei | Yes |
