FL 8/15 | Block

PCB flat transformer, 8 VA, 15 V/15 V, 266 mA/266 mA, 76 %, FL 8/15

Order No.: 35C3390
EAN: 4099891346980
MPN:
FL 8/15
Series: FL
Block
FL 8/15 Block PCB Transformers Image 1
FL 8/15 Block PCB Transformers Image 2
Image may differ
Print
Key Specification:
Output power 8 W
Primary voltage 2 x 115 V
Secondary voltage (1) 15 V
Secondary voltage (2) 15 V
Show 5 variants
Download Datasheet Technical specifications
Unit Price (€ / pc.)
23.5025 € *
Available: 14 pcs.
Leadtime: 2 Weeks **
Total Price:
23.50 € *
Price list
Quantity
Price per unit*
1 pcs.
23.5025 €
10 pcs.
20.6703 €
50 pcs.
19.2661 €
150 pcs.
18.4212 €
500 pcs.
17.4930 €
*incl. VAT plus shipping costs
**Subject to prior sale
Description
Technical specifications
Download
Logistics
Compliance
Variations

PCB transformers, flat, type Block FL.

Safety transformer for PCB mounting, epoxy resin molded plastic housing (self-extinguishing to UL 94 V-0)

Rated power 8.0 VA, type FL 8.
Technical specifications
Output power 8 W
Width 44 mm
Height 22.6 mm
Length 53 mm
Primary voltage 2 x 115 V
Secondary voltage (1) 15 V
Secondary voltage (2) 15 V
Secondary amperage 1 266 mA
secondary amperage 2 266 mA
efficiency 76 %
Show similar products 0
Logistics
Country of origin DE
Customs tariff number 85043180
Compliance
RoHS conform Yes
Date of RoHS guidelines 3/31/15
SVHC free Yes
