CUL 100/0,35 | Block

Enamel copper wire, 1 x 0.35 mm, 0.1 kg, Block CUL 100/0.35

Order No.: 89F208
EAN: 4099891167516
MPN:
CUL 100/0,35
Series: CUL
Block
CUL 100/0,35 Block Winding Wires Image 1
CUL 100/0,35 Block Winding Wires Image 2
Image may differ
Print
Key Specification:
Insulating varnish polyurethane
Cable structure 1 x 0.35 mm
Outer diameter 0.35 mm
Max. current 0.35 A
Heat resistance 155 °C

Ordering Information:

Supplied as 100 g coil
Show 27 variants
Download Datasheet Technical specifications
Unit Price (€ / pck.)
10.4839 € *
Available: 14 pck.
Leadtime: 2 Weeks **
Total Price:
10.48 € *
Price list
Quantity
Price per unit*
1 pck.
10.4839 €
10 pck.
9.2225 €
50 pck.
8.5918 €
150 pck.
8.2229 €
500 pck.
7.7945 €
*incl. VAT plus shipping costs
**Subject to prior sale
Description
Technical specifications
Download
Logistics
Compliance
Variations

Enamel insulated stranded copper wire, type Block CUL.

Solderable, grade 1

100 g coils, type CUL 100/.
Technical specifications
Outer diameter 0.35 mm
Heat resistance 155 °C
Weight 100 g
Insulating varnish polyurethane
Length 87 m
Cable structure 1 x 0.35 mm
Max. current 0.35 A
Show similar products 0
Logistics
Country of origin EU
Customs tariff number 85441110
Compliance
RoHS conform Yes
Date of RoHS guidelines 3/31/15
SVHC free Yes
