CUL 500/0,50 | Block

Enamel copper wire, 1 x 0.5 mm, 0.5 kg, Block CUL 500/0.50

Order No.: 89F272
EAN: 4099891167738
MPN:
CUL 500/0,50
Series: CUL
Block
CUL 500/0,50 Block Winding Wires Image 1
CUL 500/0,50 Block Winding Wires Image 2
Image may differ
Print
Key Specification:
Insulating varnish polyurethane
Cable structure 1 x 0.5 mm
Outer diameter 0.5 mm
Max. current 0.7 A
Heat resistance 155 °C

Ordering Information:

Supplied as 500 g coils
Show 27 variants
Download Datasheet Technical specifications
Unit Price (€ / pck.)
28.8099 € *
Available: 5 pck.
Leadtime: 2 Weeks **
Total Price:
28.81 € *
Price list
Quantity
Price per unit*
1 pck.
28.8099 €
5 pck.
27.0844 €
15 pck.
26.0491 €
50 pck.
24.8948 €
150 pck.
23.8595 €
*incl. VAT plus shipping costs
**Subject to prior sale
Description
Technical specifications
Download
Logistics
Compliance
Variations

Enamel insulated stranded copper wire, type Block CUL.

Solderable, grade 1

500 g coils, type CUL 500/.
Technical specifications
Outer diameter 0.5 mm
Heat resistance 155 °C
Weight 500 g
Insulating varnish polyurethane
Length 221 m
Cable structure 1 x 0.5 mm
Max. current 0.7 A
Show similar products 0
Logistics
Country of origin SE
Customs tariff number 85441110
Compliance
RoHS conform Yes
Date of RoHS guidelines 3/31/15
SVHC free Yes
