CM322522-4R7KL | Bourns Electronics GmbH
Choke, SMD, 4.7 µH, 220 mA, CM322522-4R7KL
Unit Price (€ / pc.)
0.2987 € *
Available: 1,960 pcs.
Leadtime: 24 Weeks **
Total Price:
5.97 € *
Price list
Quantity
Price per unit*
20 pcs.
0.2987 €
100 pcs.
0.2344 €
500 pcs.
0.1928 €
2000 pcs.
0.1702 €
4000 pcs.
0.1535 €
*incl. VAT plus shipping costs
**Subject to prior sale
Chip inductor, CM322522-4R7KL, Bourns
Features
- High resistance to heat and humidity
- Resistance to mechanical shock and pressure
- Accurate dimensions for automatic surface mounting
- RoHS compliant
Applications
- Mobile phones
- Cellular phones
- CTV, VCR, HIC, FDD
Technical specifications
| Version | Chip inductor | |
| Design | SMD | |
| Width | 2.5 mm | |
| DC current | 220 mA | |
| DC resistance | 1.5 Ω | |
| Quality Q | Q 30 | |
| Height | 2.2 mm | |
| Inductance | 4.7 µH | |
| Length | 2.9 mm | |
| Measuring frequency | 7.96 MHz | |
| Tolerance | ±10 % |
Download
Logistics
| Customs tariff number | 85045000 |
| MSL | MSL 1 |
Compliance
| RoHS conform | Yes |
| Date of RoHS guidelines | 3/31/15 |
| SVHC free | Yes |
