SRN3015-100M | Bourns Electronics GmbH
Power choke, SMD 1212, 10 µH, 1 A, SRN3015-100M
Unit Price (€ / pc.)
0.3689 € *
Available: 1,980 pcs.
Leadtime: 16 Weeks **
Total Price:
3.69 € *
Price list
Quantity
Price per unit*
10 pcs.
0.3689 €
50 pcs.
0.3213 €
250 pcs.
0.2856 €
1000 pcs.
0.2582 €
2000 pcs.
0.2356 €
*incl. VAT plus shipping costs
**Subject to prior sale
SMD power inductor, semi-shielded, type Bourns SRN2010.
Measuring frequency: 1.0 MHz at 0.1 V. Operating temperatures: –55 to +125 °C. Tolerance: 20 %. Carrier material: Ferrite.
SMD power choke half shielded type Bourns SRN3015.
Operating temperature: –40 to +125 °C, Dimensions: 3,0 x 3,0 x 1,5 mm, Carrier material: Ferrite. Table data: Type, Inductance, Rated current, max. DC resistance, Measuring frequency, Quality factor Q, Resonance frequency, Tolerance.
Technical attributes (type, rated inductance, rated current, max. DC resistance): SRN3015-100M, 10 µH, 0,88 A, 276 mOhm, 2,52 MHz, Q 10, 30 MHz, 20 %
Technical specifications
| Ausführung | Leistungsdrossel | |
| Induktivität | 10 µH | |
| Gleichstrom | 1 A | |
| Toleranz | ±20 % | |
| Gleichstromwiderstand | 276 mΩ | |
| Sättigungsstrom | 880 mA | |
| Messfrequenz | 7.96 MHz | |
| Gütefaktor Q | Q 16 | |
| Bauform | SMD 1212 | |
| Länge | 3 mm | |
| Breite | 3 mm | |
| Höhe | 1.5 mm |
Download
Logistics
| Ursprungsland | TW |
| Zolltarifnummer | 85045000 |
| MSL | MSL 1 |
| Originalverpackung | Rolle mit 2.000 Stück |
Compliance
| RoHS konform | Yes |
| Stand der RoHS-Richtlinie | 3/31/15 |
| SVHC frei | Yes |
