SRN8040-1R0Y | Bourns Electronics GmbH
Power choke, SMD, 1 µH, SRN8040-1R0Y
Unit Price (€ / pc.)
0.4522 € *
Available: 0 pcs.
Leadtime: 16 Weeks **
Power inductor, SRN8040-1R0Y, Bourns
Features
- Semi-shielded construction
- Ferrite core
- High rated current
- Component height: 4 mm
- RoHS compliant
Applications
- DC/DC converters
- Notebook computers
- Digital video cameras
- HDDs, cellphones
- Televisions, LCD displays
Technical specifications
| Ausführung | Leistungsdrossel | |
| Bauform | SMD | |
| Breite | 7.9 mm | |
| Gleichstromwiderstand | 10 mΩ | |
| Gütefaktor Q | Q 13 | |
| Höhe | 4 mm | |
| Induktivität | 1 µH | |
| Länge | 8.15 mm | |
| Messfrequenz | 7.96 MHz | |
| Sättigungsstrom | 11 A | |
| Toleranz | ±30 % |
Download
Logistics
| Zolltarifnummer | 85045000 |
| MSL | MSL 1 |
Compliance
| RoHS konform | Yes |
| Stand der RoHS-Richtlinie | 3/31/15 |
| SVHC frei | Yes |
