CRL1206-FW-R100ELF | Bourns Electronics GmbH
Resistor, thick film, SMD 1206 (3216), 100 mΩ, 0.25 W, ±1 %, CRL1206-FW-R100ELF
Unit Price (€ / pc.)
0.0666 € *
Available: 3,800 pcs.
Leadtime: 18 Weeks **
Total Price:
6.66 € *
Price list
Quantity
Price per unit*
100 pcs.
0.0666 €
500 pcs.
0.0583 €
1000 pcs.
0.0524 €
5000 pcs.
0.0464 €
*incl. VAT plus shipping costs
**Subject to prior sale
SMD Thick film resistor, CRL1206-FW-R100ELF, Bourns
Resistor, Thick film, SMD 1206, 100 mΩ, 0.25 W, ±1 %
Features
- Values from 0.02 to 9.10 ohms
- Tape and reel packaging
- RoHS compliant
Technical specifications
| ohmscher Widerstand | 100 mΩ | |
| Bauform | SMD 1206 (3216) | |
| Breite | 1.6 mm | |
| Höhe | 0.6 mm | |
| Länge | 3.2 mm | |
| Leistung | 0.25 W | |
| max. Temperatur | 125 °C | |
| min. Temperatur | -55 °C | |
| Toleranz | ±1 % | |
| Technologie | Dickschicht | |
| Temperaturkoeffizient | ±200 ppm/K |
Download
Logistics
| Ursprungsland | TW |
| Zolltarifnummer | 85332100 |
| MSL | MSL 1 |
| Originalverpackung | Rolle mit 5.000 Stück |
Compliance
| RoHS konform | Yes |
| Stand der RoHS-Richtlinie | 3/31/15 |
| SVHC frei | Yes |
