3005P-1-103 | Bourns Electronics GmbH
Trimmer potentiometer, 20 turns, 10 kΩ, 1 W, THT, lateral, 3005P-1-103
Unit Price (€ / pc.)
18.6592 € *
Available: 0 pcs.
Leadtime: 11 Weeks **
Trimmer potentiometer, 3005P-1-103, Bourns Electronics GmbH
Rectangular 3/4 inches trimming potentiometer. Designed to be sealed in order to protect it from any potential contamination that may occur during fluxing, soldering, and cleaning processes.
Technical specifications
| ohmscher Widerstand | 10 kΩ | |
| Anschluss | Lötstift | |
| Ausführung | Trimmpotentiometer | |
| Breite | 4.06 mm | |
| Drehbereich (elektrisch) | 7200 ° | |
| Einstellung | seitlich | |
| Höhe | 7.87 mm | |
| Kontaktabstand | RM 2,54 | |
| Länge | 19.03 mm | |
| Leistung | 1 W | |
| max. Anzahl der Umdrehungen | 20 | |
| max. Temperatur | 125 °C | |
| min. Temperatur | -65 °C | |
| Montage | THT | |
| Toleranz | ±10 % | |
| Temperaturkoeffizient | ±50 ppm/K | |
| Widerstandsverlauf | linear |
Download
Logistics
| Ursprungsland | MX |
| Zolltarifnummer | 85334010 |
| MSL | MSL 2 |
| Originalverpackung | Stange mit 25 Stück |
Compliance
| RoHS konform | Yes |
| Stand der RoHS-Richtlinie | 3/31/15 |
| SVHC frei | No |
| Substanz Beschreibung | Cadmium, Blei |
