3299Y-1-504LF | Bourns Electronics GmbH
Cermet trimmer potentiometer, 25 turns, 500 kΩ, 0.5 W, THT, on top, 3299Y-1-504LF
Unit Price (€ / pc.)
4.2126 € *
Available: 45 pcs.
Leadtime: 13 Weeks **
Total Price:
4.21 € *
Price list
Quantity
Price per unit*
1 pcs.
4.2126 €
10 pcs.
3.7009 €
100 pcs.
3.2487 €
200 pcs.
3.1297 €
1000 pcs.
2.8679 €
*incl. VAT plus shipping costs
**Subject to prior sale
Trimmer potentiometer, 3299Y-1-504LF, Bourns Electronics GmbH
3/8 inches square trimming potentiometer. Equipped with a standoff for added convenience.
Technical specifications
| ohmscher Widerstand | 500 kΩ | |
| Anschluss | Lötstift | |
| Ausführung | Cermet-Trimmpotentiometer | |
| Breite | 9.53 mm | |
| Drehbereich (elektrisch) | 9000 ° | |
| Einstellung | oben | |
| Höhe | 6.1 mm | |
| Kontaktabstand | RM 5,08/2,54 | |
| Länge | 10.03 mm | |
| Leistung | 0.5 W | |
| max. Anzahl der Umdrehungen | 25 | |
| max. Temperatur | 125 °C | |
| min. Temperatur | -55 °C | |
| Montage | THT | |
| Toleranz | ±10 % | |
| Temperaturkoeffizient | ±100 ppm/K | |
| Widerstandsverlauf | linear |
Download
Logistics
| Ursprungsland | CR |
| Zolltarifnummer | 85334010 |
| MSL | MSL 2 |
| Originalverpackung | Stange mit 50 Stück |
Compliance
| RoHS konform | Yes |
| Stand der RoHS-Richtlinie | 3/31/15 |
| SVHC frei | No |
| Substanz Beschreibung | Blei |
