ISOM5-175-B-L2 | Bourns Electronics GmbH

Hybrid protection component, radial, 10000 A, 225 V (DC), 175 V (AC), ISOM5-175-B-L2

Order No.: 07E5558
EAN: 4099879986436
MPN:
ISOM5-175-B-L2
Series: IsoMOV
Bourns Electronics GmbH
ISOM5-175-B-L2 Bourns Electronics GmbH Varistors Image 1
ISOM5-175-B-L2 Bourns Electronics GmbH Varistors Image 2
Image may differ
Unit Price (€ / pc.)
0.9996 € *
Available: 0 pcs.
Leadtime: 16 Weeks **
Total Price:
1.00 € *
*incl. VAT plus shipping costs
**Subject to prior sale
3000 pcs.
0.9996 €

Varistor series IsoMOV

By combining the best features of both MOV and GDT technologies in a single component, the IsoMOV™ series achieves high performance with low capacitance, very low leakage current and excellent power handling density. The IsoMOV™ series is ideally suited for AC and DC power supply applications where highest performance and/or space savings are required.

Technical specifications
Design radial
max. Surge current, transient (8/20 µs) 10000 A
max. operating temperature 125 °C
min. operating temperature -40 °C
Rated voltage (AC) 175 V
Rated voltage (DC) 225 V
Standard number UL, CSA
Grid 7.5 mm
Logistics
Country of origin CR
Customs tariff number 85334090
MSL MSL 1
Original Packaging Bulk with 300 pieces
Compliance
RoHS conform Yes
Date of RoHS guidelines 3/31/15
SVHC free Yes
