SW-114 | BRAINBOXES
Ethernet switch, unmanaged, 4 ports, 100 Mbit/s, 5-30 VDC, SW-114
Order No.: 06P8061
EAN: 837324004939
MPN:
SW-114
Unit Price (€ / pc.)
94.8787 € *
Available: 0 pcs.
Leadtime: On Request **
Total Price:
94.88 € *
Price list
Quantity
Price per unit*
1 pcs.
94.8787 €
2 pcs.
92.9747 €
5 pcs.
90.8565 €
*incl. VAT plus shipping costs
**Subject to prior sale
Ethernet Switch, SW-114, BRAINBOXES
Embedded industrial 4 port Gigabit Ethernet unmanaged switch. Galvanically Isolated Ethernet Ports. Automatic detection of data transmission speed: 10/100/1000 Mbps. Industrial temperature range of -40°C to +80°C and dual input redundant power supply with wide voltage range means it can be powered from USB or on the 24V factory floor. Power terminal is removable with numbered pins for easy wiring. Power consumption is optimised based on the status of the link device.
No software required. Ideal for embedded applications.
Features
- Automatic detection of data transmission speed: 10 or 100 or 1000 Mbps
- Can be powered by a variety of sources
- All Ethernet ports are Auto MDI/ MDIX supporting straight through or crossover Ethernet cables
- Power consumption is optimised based on the status of the link device
- Easy Wire Removable screw terminal block
Technical specifications
| Version | Ethernet Switch, unmanaged | |
| Data transmission rate | 100000000 mb/s | |
| Assembly | Rack-Montage | |
| Ports | 4 | |
| Voltage | 5-30 VDC |
Download
Logistics
| Country of origin | GB |
| Customs tariff number | 85176200 |
Compliance
| RoHS conform | Yes |
| Date of RoHS guidelines | 3/31/15 |
| SVHC free | Yes |
