PX0411/12S/6065 | BULGIN

Jack, 12 pole, crimp connection, screw locking, straight, PX0411/12S/6065

Order No.: 70F5084
EAN: 4099889737721
MPN:
PX0411/12S/6065
PX0411/12S/6065 BULGIN Other Circular Connectors
Image may differ
Unit Price (€ / pc.)
13.5898 € *
Available: 0 pcs.
Available in 5 Days: 29 pcs.
Leadtime: 22 Weeks **
Total Price:
203.85 € *
Price list
Quantity
Price per unit*
15 pcs.
13.5898 €
45 pcs.
11.4240 €
*incl. VAT plus shipping costs
**Subject to prior sale

Circular connector series 400, type Bulgin PX04.

With flexible cable connection; Contact resistance: max. 5.0 mohm. Material: polyamide to UL 94 V-0. Degree of protection: IP 68. Operating temperatures: –40 to +80 °C. Contacts are available on separate order.

Cable socket housings with female contact insert, type PX0411.

Technical attributes (type, number of poles, rated voltage/current, cable diameter): PX0411/12S/6065, 12-pole, 50 V AC/DC/1.0 A, 6.0 to 6.5 mm

Technical specifications
Ausführung Buchse
Bestückung unbestückt
Gehäusematerial PA
Kabeldurchmesser 6 bis 6,5 mm
Kontaktanschluss Crimpanschluss
Montage Kabelmontage
Orientierung gerade
Polzahl 12-polig
Verriegelung Schraubverriegelung
Logistics
Ursprungsland TN
Zolltarifnummer 85366990
Compliance
RoHS konform Yes
Stand der RoHS-Richtlinie 3/31/15
SVHC frei No
Substanz Beschreibung Blei
