MP915-50.0-1% | Caddock
Power metal film resistor, 50 Ω, 15 W, ±1 %, MP915-50.0-1%
Unit Price (€ / pc.)
5.7596 € *
Available: 79 pcs.
Leadtime: 3 Weeks **
Total Price:
5.76 € *
Price list
Quantity
Price per unit*
1 pcs.
5.7596 €
10 pcs.
5.0694 €
100 pcs.
4.4506 €
200 pcs.
4.2721 €
1000 pcs.
3.9270 €
*incl. VAT plus shipping costs
**Subject to prior sale
Power metal film resistors, 15 to 100 W, tolerance 1.0 %, TO package, type Caddock MP 915/925/930/9100.
Low inductance, mountable on heatsinks, with heat dissipating ceramic mounting surface
Rated load 15 W, type MP 915.
Technical specifications
| ohmscher Widerstand | 50 Ω | |
| Ausführung | Leistungs-Metallfilmwiderstand | |
| Bauform | radial | |
| Breite | 2.79 mm | |
| Höhe | 11.18 mm | |
| Länge | 8.12 mm | |
| Leistung | 15 W | |
| max. Temperatur | 150 °C | |
| min. Temperatur | -55 °C | |
| Montage | THT | |
| Toleranz | ±1 % | |
| Temperaturkoeffizient | -20/80 ppm/K |
Download
Logistics
| Ursprungsland | US |
| Zolltarifnummer | 85332100 |
| Originalverpackung | Stange mit 50 Stück |
Compliance
| RoHS konform | Yes |
| Stand der RoHS-Richtlinie | 3/31/15 |
| SVHC frei | Yes |
