PXS59150 | Celduc Relais

Proximity switch, screw mounting, 1 Form A (N/O) + 1 Form B (N/C), 3 W, 100 V (DC), 0.1 A, Detection range 8 mm, PXS59150

Order No.: 45P4628
EAN: 3760283303782
MPN:
PXS59150
Series: PXS
Celduc Relais
PXS59150 Celduc Relais Proximity Switches, Reed switches
Image may differ
Unit Price (€ / pc.)
85.68 € *
Available: 0 pcs.
Available in 5 Days: 11 pcs.
Leadtime: On Request **
Total Price:
85.68 € *
*incl. VAT plus shipping costs
**Subject to prior sale
10 pcs.
85.68 €

Safety magnetic switch, PXS59150, Celduc Relais

Sensor alone with a cable of 5 meter, with LED and serial resitance of 10Ω.

Technical specifications
Connection cable connection
Version proximity sensor
Detection range 8 mm
Length 88 mm
Assembly screw mounting
Latching switching function 1 Form A (N/O) + 1 Form B (N/C)
Breaking capacity 3 W
Switching Voltage (AC) 48 V
Switching Voltage (DC) 100 V
switching current 0.1 A
Degree of protection (IP) IP66/IP67
Logistics
Country of origin FR
Customs tariff number 85365080
Compliance
RoHS conform Yes
Date of RoHS guidelines 3/31/15
SVHC free Yes
