45021 | CM Manufactory
Safety relays, 4 Form A (N/O) + 1 Form B (N/C), 24 V AC/DC, 45021
Unit Price (€ / pc.)
166.9808 € *
Available: 0 pcs.
Leadtime: 1 Week **
Total Price:
166.98 € *
Price list
Quantity
Price per unit*
1 pcs.
166.9808 €
5 pcs.
166.1657 €
10 pcs.
165.3505 €
*incl. VAT plus shipping costs
**Subject to prior sale
Safety controller, 45021, CM Manufactory
The 45021 is a safety switching device for contact multiplication in emergency stop circuits, protective door monitoring circuits and other safety circuits in accordance with DIN EN 60204. The device is designed for one or two channel operation. It also has cross-circuit monitoring.
Technical specifications
| Version | safety switching device | |
| Width | 22.5 mm | |
| Input voltage AC | 24 V AC/DC | |
| Height | 99 mm | |
| Contact type | 4 Form A (N/O) + 1 Form B (N/C) | |
| Assembly | DIN rail | |
| Depth | 114.5 mm | |
| Type of Use | for contact multiplication |
Download
Logistics
| Country of origin | DE |
| Customs tariff number | 85364190 |
Compliance
| RoHS conform | Yes |
| Date of RoHS guidelines | 3/31/15 |
| SVHC free | No |
| Substance description | Lead |
