TIP150-T | COMSET Semiconductors
Bipolar junction transistor, NPN, 7 A, 300 V, THT, TO-220, TIP150-T
Unit Price (€ / pc.)
3.1535 € *
Available: 36 pcs.
Next delivery: 500 pcs. on 2025-01-03
Leadtime: On Request **
Total Price:
3.15 € *
Price list
Quantity
Price per unit*
1 pcs.
3.1535 €
10 pcs.
2.2491 €
100 pcs.
1.9278 €
500 pcs.
1.6779 €
1000 pcs.
1.5232 €
*incl. VAT plus shipping costs
**Subject to prior sale
NPN power transistor, TIP150-T, COMSET
The TIP150-T is a NPN epitaxial-base transistors in a monolithic Dalrington circuit and housed in a TO-220 enveloppe. High voltage, high forward and reverse energy designed for industrial and consumer applications.
Features
- Compliance to RoHS
Technical specifications
| Version | NPN | |
| Enclosure | TO-220 | |
| max. operating temperature | 150 °C | |
| max.voltage between collector and base Vcbo | 300 V | |
| max.voltage between collector and emitter Vceo | 300 V | |
| min. operating temperature | -65 °C | |
| Assembly | THT | |
| Rated current | 7 A | |
| Saturation voltage | 1.5 V | |
| Power dissipation | 80 W | |
| Collector current | 7 A | |
| Min DC gain | 15 mA |
Download
Logistics
| Country of origin | CN |
| Customs tariff number | 85412900 |
| Original Packaging | Bar with 50 pieces |
Compliance
| RoHS conform | Yes |
| Date of RoHS guidelines | 3/31/15 |
| SVHC free | Yes |
