F/UCW12 | Digisound
Signal transmitter, 83 dB, 12 VDC, 30 mA, black, F/UCW12
Order No.: 36M4756
EAN: 4099891542047
MPN:
F/UCW12
Unit Price (€ / pc.)
2.0468 € *
Available: 881 pcs.
Leadtime: 23 Weeks **
Total Price:
2.05 € *
Price list
Quantity
Price per unit*
1 pcs.
2.0468 €
25 pcs.
1.7374 €
100 pcs.
1.6065 €
250 pcs.
1.5232 €
1000 pcs.
1.3923 €
*incl. VAT plus shipping costs
**Subject to prior sale
Buzzers, type Digisound F/UCW.
With electronic system, miniature design, low current consumption. Penetrating, yet discrete warning sound. High reliability, sealed horn opening; Frequency: 2300 Hz (±500 Hz). Sound pressure level (10 cm): min. 83 dB (A), type F/UCW 01 min. 75 dB (A). Weight: 2.0 g.
Technical attributes (type, operating voltage, rated voltage, current consumption at rated voltage): F/UCW 12, 9.0 to 15 VDC, 12 V, 30 mA
Technical specifications
| Version | signal transmitter | |
| Colour | black | |
| Rated current | 30 mA | |
| Resonance frequency | 2300 Hz | |
| Sound pressure level | 83 db | |
| Voltage | 12 VDC |
Download
Logistics
| Country of origin | CN |
| Customs tariff number | 85318070 |
Compliance
| RoHS conform | Yes |
| Date of RoHS guidelines | 3/31/15 |
| SVHC free | Yes |
