B250C7000-4000A | Diotec
Diotec bridge rectifier, 250 V, 600 V (RRM), 7 A, SIL, B250C7000-4000A
Unit Price (€ / pc.)
1.1305 € *
Available: 12 pcs.
Available in 4 Days: 370 pcs.
Leadtime: 18 Weeks **
Total Price:
1.13 € *
Price list
Quantity
Price per unit*
1 pcs.
1.1305 €
25 pcs.
0.9639 €
100 pcs.
0.8806 €
*incl. VAT plus shipping costs
**Subject to prior sale
Diode bridge rectifier, B250C7000-4000A, DIOTEC
Features
- Four diodes in bridge configuration
- For free-standing or heatsink assembly
- UL recognized
- Compliant to RoHS, REACH and conflict minerals
Applications
- 50/60 Hz mains rectification
- Power supplies
- Commercial grade
Technical specifications
| Version | 1-phase | |
| Input voltage | 250 V | |
| Enclosure | SIL | |
| max. operating temperature | 150 °C | |
| min. operating temperature | -50 °C | |
| Assembly | THT | |
| Rated current | 7 A | |
| Voltage V RRM (peak reverse voltage) | 600 V |
Download
Logistics
| Country of origin | SI |
| Customs tariff number | 85411000 |
Compliance
| RoHS conform | Yes |
| Date of RoHS guidelines | 3/31/15 |
| SVHC free | Yes |
