B500C7000-4000A | Diotec
Diotec bridge rectifier, 500 V, 1 kV (RRM), 7 A, SIL, B500C7000-4000A
Unit Price (€ / pc.)
2.1658 € *
Available: 415 pcs.
Leadtime: 18 Weeks **
Total Price:
2.17 € *
Price list
Quantity
Price per unit*
1 pcs.
2.1658 €
10 pcs.
1.7850 €
100 pcs.
1.5351 €
250 pcs.
1.3923 €
1000 pcs.
1.2733 €
*incl. VAT plus shipping costs
**Subject to prior sale
Diode bridge rectifier, B500C7000-4000A, DIOTEC
Features
- Four diodes in bridge configuration
- For free-standing or heatsink assembly
- UL recognized
- Compliant to RoHS, REACH and conflict minerals
Applications
- 50/60 Hz mains rectification
- Power supplies
- Commercial grade
Technical specifications
| Ausführung | 1-phase | |
| Eingangsspannung | 500 V | |
| Gehäuse | SIL | |
| max. Temperatur | 150 °C | |
| min. Temperatur | -50 °C | |
| Montage | THT | |
| Nennstrom | 7 A | |
| Spannung V RRM (Spitzensperrspannung) | 1 kV |
Download
Logistics
| Ursprungsland | SI |
| Zolltarifnummer | 85411000 |
Compliance
| RoHS konform | Yes |
| Stand der RoHS-Richtlinie | 3/31/15 |
| SVHC frei | Yes |
