106-P30-0,3A | E-T-A
Thermal circuit breaker, 1 pole, 300 mA, 48 V (DC), 240 V (AC), faston plug 2.8 x 0.8 mm, central Mounting, IP40, 106-P30-0,3A
Unit Price (€ / pc.)
18.5878 € *
Available: 32 pcs.
Leadtime: 4 Weeks **
Total Price:
18.59 € *
Price list
Quantity
Price per unit*
1 pcs.
18.5878 €
10 pcs.
16.3625 €
*incl. VAT plus shipping costs
**Subject to prior sale
Device circuit breaker, 106-P30-0,3A, E-T-A
The 106-P30-0,3A is a single-pole, thermal circuit breaker that comes with a small design. It has a reliable switching behavior due to snap-action mechanism and uninfluenced free tripping.
Features
- High dielectric strength
Applications
- Hand tools
- Household appliances
- Overcurrent protection of conductors
- Printed circuits
- Watercraft
- Motorhomes
Technical specifications
| Anschluss | Flachstecker 2,8 x 0,8 mm | |
| Befestigungsart | Zentralbefestigung | |
| Betätiger | Druckknopf | |
| Nennspannung (AC) | 240 V | |
| Nennspannung (DC) | 48 V | |
| Nennstrom | 300 mA | |
| Polzahl | 1-polig | |
| Schutzart (IP) | IP40 |
Download
Logistics
| Ursprungsland | TN |
| Zolltarifnummer | 85362010 |
Compliance
| RoHS konform | Yes |
| Stand der RoHS-Richtlinie | 3/31/15 |
| SVHC frei | No |
| Substanz Beschreibung | Blei |
